the comparison

oenostar 1000 mc

oenostar 2000 ha

oenostar 2000 ha advanced

oenostar 3000 a

Number of modules

2 x E-95

4 x E-95

4 x E-9

6 x E-95 (expandable)

Total membrane surface area

20 m²

40 m²

40 m²

60 m²

Nominal filter capacity
(white wine)

1.000 l/h –
1.700 l/h

2.000 l/h –
3.700 l/h

2.000 l/h –
3.700 l/h

3.000 l/h –
5.000 l/h

Nominal filter capacity
(red wine)

700 l/h –
1.300 l/h

1.400 l/h –
2.400 l/h

1.400 l/h –
2.400 l/h

2.100 l/h –
3.500 l/h

Batch size

250 l –
7.500 l

1.000 l –
20.000 l

1.000 l –
20.000 l

3.000 l –
50.000 l

Electrical power consumed

4 kW

5 kW | 6.5 kW

5 kW | 6.5 kW

12 kW | 12 kW

Dimensions (L x W x H)

1.300 x 850 x 1.950

1.700 x 850 x 2.000

1.800 x 950 x 2.100

1.720 x 980 x 2.110

Weight

230 kg

335 kg

480 kg

750 kg

Membrane material

Polyether-
sulfone (PES)

Polyether-
sulfone (PES)

Polyether-
sulfone (PES)

Polyether-
sulfone (PES)

Dead space volume

< 12 l

18 - 22 l

18 - 22 l

40 - 60 l

Separation limit

Microfiltration

Microfiltration

Microfiltration

Microfiltration
